Praher Diverter Valve 3 Port 1.5″ Unions Perma Seal – Ov3-1500U

Description

Praher 3 Port Valve 1.5″ with Unions

• MPN: OV3-1500U
• Disagreement on actual UPC Code:
  UPC 682470331732 UPC: 885531001272 UPC: 885531001163

Uses internal replacement Diverter OV3-200-7

• The Praher 3-Way Rotor Valves are available in sizes 1.5″ & 2″ slip.
• The unique design allows the 1.5″ slip models to also allow for a 2″ spigot connection and the 2″ slip models to also allow for a 2.5″ spigot connection.
• The position indicator plate gives operators a clear read out of the valve position.
• Tightening the handle knob allows you to lock the valve in a desired position.
• Size: 1 1/2″ slip – 2″ spigot
• Material: CPVC body black, Glass filled Noryl rotor, ABS handle
• O-Rings: NITRILE
• Rotor Seal: High temperature silicone gasket with teflon jacket
• Pressure Rating: 50 PSI
• Positive seal back pressure: 15 PSI
• Vacuum Rating: 29″ Mercury

FEATURES:

• High heat lid that will not warp in the sun
• Proportional mixing availability
• Double O-ring shaft seal
• Permanently lubricated rotor seal with extreme wear resistance, exceeds 3000 dry cycle requirement
• Chlorine, acid and ozone resistant construction
• Handle-locking knob provides eye-let for lock attachment
• Engineered “PLAST-TITE” screws (18.8 stainless) will not crack plastic when servicing valve
• Universal shaft spline pattern adapts to most actuators
• All wetted materials are of NSF-50 or 61 designation
• Patented design US 6497250
